Product Details:
Place of Origin: China
Brand Name: Learnew Opto
Certification: RoHS CE ISO
Model Number: 1414 1919 2828 4046 LED SERIES
Payment & Shipping Terms:
Minimum Order Quantity: 5000-10000
Price: Negotiable
Packaging Details: Anti-static Blister Packing
Delivery Time: 15-45 working days
Payment Terms: T/T, CNY;Paypal,Negotiable
Supply Ability: 200000PCS/Monthly
Contact Now

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White

Description
POWER: 10-15W;15-30W;25-35W;35-50W;40-60W;50-80W;80-120W;150-200W CCT: 2700-6500K
Whole Size: 19*19MM;14*14MM;28*28MM;40*46MM Voltage: 35-38V;30-33V;42-48V
Chips: F1430 LM/W: 100-140
Highlight:

1414 Flip Chip LED

,

1919 Flip Chip LED

,

COB LED CHIP 2828

Flip Chip 1414 1919 2828 4046 High Power 5w 10w 30w 50w 100w 200w 150W White Color COB LED CHIP

Product Descriptions

Power 10-15W;15-30W;25-35W;35-50W;40-60W;50-80W;80-120W;150-200W
CCT 2700-6500K
LM/W 100-140
Whole Size 19*19MM;14*14MM;28*28MM;40*46MM
Current 280-400mA;400-800mA;700-1000mA;900-1200mA;1100-1500mA;1350-2200mA;1250-1800mA;2500-4000mA;3500-4500mA
Emit Size R11MM;R17MM;R23MM;25*25MM
Voltage 35-38V;30-33V;42-48V
Circuit 12S2P;12S4P;12S7P;12S8P;12S12P;10S10P;10S21P;14S30P
CRI 70/80/90/95/97/98
Substrate Super-Aluminum
Design Advantage 1,High density
2,High power series
3,Low thermal resistance
4,SDCM<5
5,CRI available in 80/90/95+
6,Flip chip technology
7,Good stability
View Angle 120°
Application 1,LED spotlight
2,LED car light
3,LED downlight
4,LED tracking light
5,LED wall lamp
6,LED bulb
7,LED floodlight
8,LED streetlight

Product Pictures

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 0

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 1

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 2

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 3

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 4

Company Profile&Factory&Certification&Shipping Info

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 5

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 6

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 7

1414 1919 2828 4046 High Power Flip Chip LED 5w 10w 30w 50w 100w 200w 150W White 8

FAQ:

Q1: Do you supply OEM,ODM service?
A1: YES,absolutely it can be realized.Learnew focus on OEM & ODM service more than 7 years.

Q2:All the pictures are real photo?

A2: Yes, the pictures of all products on this page are 100% real shoot by us.

Q3: How can I get a quotation from you?
A3: Please kindly leave us messages about your needs,including products parameters,application, you contact way and quantity,our professional team will reply you in one hour here.

Q4: Is there any discount for bulk order?
A4: Yes, if you need bulk order or you want customized products, we can provide wholesale price. Be our fans on alibaba or add learnew opto to “my favorite stores”, you will always get our discount and coupon information at the first time.

Q5: Do you support drop shipping and how much is the shipping cost?
A5: Yes, we support drop shipping. You should leave the receiver's information when you place the order, then we will send the goods according the address you have left. The shipping cost are based on your order's volume and weight, you can check on alibaba or ask our team.

Q6: How to place an order?
A6: You can check the shipping cost and discount information online, and place order directly on Alibaba. Or you can contact us for the order details, we will reply you in mins.

Q7: What payment terms are available?
A7: T/T,PayPal, Western Union and Secure Payment.

Q8: What about the lead time?
A8: It depends on the order quantity. In general, lead time is about 10-15 working days. For samples in standard, the delivery could be 3 days.ng Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
