Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip

Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip
Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip
Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip

Large Image :  Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip

Product Details:
Place of Origin: China
Brand Name: Learnew Opto
Certification: CE/ROHS
Model Number: UVA LED SERIES
Payment & Shipping Terms:
Minimum Order Quantity: 1000
Price: negotiable
Packaging Details: Choose packaging materials with better cushioning and protection effect. For lamps with higher value or lamps with more glass surface, we use the outer box and add a wooden box or wooden frame to the packaging.
Delivery Time: 7-15 work days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 500000
Contact Now

Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip

Description
Name: LEARNEW UVC LED DIODE POWER: 0.5-10W
Dominant Wavelength: 220-280 Optical Power: 4-120mW
WHOLE SIZE: 3.5*3.5MM \4.0*4.0MM\ 6.0*6.0MM VIEW ANGLE: 120°
LENS: QUARTZ GLASS LENS SUBSTRATE: ALN Coppering
Life Span: LM70=5000Hrs LM50=10000Hrs JUNCTION TEMPERATURE: 60C
Highlight:

ALN Coppering UVC LED Chips

,

10w UVC LED Chips

,

UVC 3535 LED Chip

LEAENEW OEM ODM FACTORY LED UVC CHIP 3535  0.5-3W  250-405MN For UVC Disinfection LED Lamp



3535 led chip Product specification



POWER Dominant Wavelength Optical Power IF VF WHOLE SIZE VIEW ANGLE LENS SUBSTRATE Life span JUNCTION TEMPERATURE
1W 270-280nm 20-30mW 100mA
(max=150mA)		 5-7V 3.5*3.5MM 120° QUARTZ GLASS LENS ALN Coppering LM70=5000Hrs
LM50=10000Hrs		 60C
260-270nm 20-30mW
250-260nm 20-30mW
0.5W 265-285nm 6-8mW 40mA
(max=50mA)		 5-7V 3.5*3.5MM 120° QUARTZ GLASS LENS ALN Coppering LM70=3000Hrs
LM50=6000Hrs		 60C
0.5W 265-285nm
(Sterilization)		 6-8mW 50mA
(max=60mA)		 5-7V 3.5*3.5MM 120° QUARTZ GLASS LENS ALN Coppering 60C
395-405nm
(Assist)		 20-40mW 50mA
(max=60mA)		 3.0-3.6V
0.5W 265-285nm
(Sterilization)		 4-6mW 50mA 5-7V 3.5*3.5MM 120° QUARTZ GLASS LENS ALN Coppering LM70=2000Hrs
LM50=5000Hrs		 60C
395-405nm
(Assist)		 50-70mW 3.0-3.6V
3W 270-280nm 50-70mW 350-500mA 5-7V 3.5*3.5MM 120° QUARTZ GLASS LENS ALN Coppering LM70=2000Hrs
LM50=5000Hrs		 60C
260-270nm 50-70mW
250-260nm 50-70mW



Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip 0

UVC chip Design Advantage

  • Quartz glass package
  • High radiant flux
  • Narrow Wavelength
  • Inorganic & Nitrogen package
  • Low thermal resistance

UVC CHIP Application

  • ICU Hospital
  • Air purifier
  • Water purifier
  • Washing machines
  • Sterilization...



Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip 1Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip 2Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip 3Multiple Wavebands UVC LED Chips , 0.5w-10w 220-280nm 250-260nm 3535 LED Chip 4

​3535 LED FAQ

Q1: Do you supply OEM,ODM service?
A1: YES,absolutely it can be realized.Learnew focus on OEM & ODM service more than 7 years.
Q2:All the pictures are real photo?

A2: Yes, the pictures of all products on this page are 100% real shoot by us.
Q3:How can I get a quotation from you?
A3: Please kindly leave us messages about your needs,including products parameters,application, you contact way and quantity,our professional team will reply you in one hour here.
Q4: Is there any discount for bulk order?
A4: Yes, if you need bulk order or you want customized products, we can provide wholesale price. Be our fans on alibaba or add learnew opto to “my favorite stores”, you will always get our discount and coupon information at the first time.
Q5: Do you support drop shipping and how much is the shipping cost?
A5: Yes, we support drop shipping. You should leave the receiver's information when you place the order, then we will send the goods according the address you have left. The shipping cost are based on your order's volume and weight, you can check on alibaba or ask our team.
Q6: How to place an order?
A6: You can check the shipping cost and discount information online, and place order directly on Alibaba. Or you can contact us for the order details, we will reply you in mins.
Q7: What payment terms are available?
A7: T/T,PayPal, Western Union and Secure Payment.
Q8: What about the lead time?
A8: It depends on the order quantity. In general, lead time is about 10-15 working days. For samples in standard, the delivery could be 3 days.ng Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
